Get the job done with the right equipment

Hydraulink provides a ‘matched system’ of hose and fittings, ensuring our products are engineered to work together to exceed international SAE and ISO standards and deliver outstanding application and safety performance. Our matched system provides optimal function, minimises risk and guarantees hose performance and safety for ultimate peace of mind when using Hydraulink as your supplier.

Hydraulink’s quality product is available in a complete range of braided and multispiral hydraulic hoses - for low to ultra high pressure applications. Our hose range includes speciality products for high abrasion, tight bend radius and high temperature applications.

The other integral part of the guaranteed matched system is Hydraulink’s fittings range which are manufactured to SAE and ISO standards - using premium steel stock sourced from European steel mills. Our comprehensive range of fittings is industry leading with over 5,000 product lines.

To compliment our product range, we also offer an assortment of accessories including Adaptors, Quick Release Couplers, Tube Clamps, Ball Valves, Assembly Equipment and Premium Hydraulic Oils.

  • Product Catalogue
  • Promotions
  • Our Agencies
  • Our Quality
  • Safety Data Sheets

BSP PARALLEL

BSP FEMALE STRAIGHT

BSP PARALLEL

BSP FEMALE STRAIGHT

BSP PARALLEL

BSP FEMALE STRAIGHT

BSP 60° CONE FEMALE SWIVEL NUT STRAIGHT

PartNumber
BSPP Female Thread (T)
Hose I.D inches
Hose I.D (mm)
Dash size
Hex A/F (E)
Cutoff - C
P01-0204
1/8-28
1/4
6.4
04
14
14
P01-0404
1/4-19
1/4
6.4
04
19
14
P01-0406
1/4-19
3/8
9.5
06
19
14
P01-0604
3/8-19
1/4
6.4
04
22
16
P01-0606
3/8-19
3/8
9.5
06
22
16
P01-0608
3/8-19
1/2
12.7
08
22
17
P01-0806
1/2-14
3/8
9.5
06
27
18
P01-0808
1/2-14
1/2
12.7
08
27
19
P01-0810
1/2-14
5/8
15.9
10
27
19
P01-0812
1/2-14
3/4
19
12
27
19
P01-1010
5/8-14
5/8
15.9
10
28
18
P01-1208
3/4-14
1/2
12.7
08
32
21
P01-1212
3/4-14
3/4
19
12
32
21

Product Data

P01-0204

BSPP Female Thread (T)

1/8-28

Hose I.D inches

1/4

Hose I.D (mm)

6.4

Dash size

04

Hex A/F (E)

14

Cutoff - C

14

P01-0404

BSPP Female Thread (T)

1/4-19

Hose I.D inches

1/4

Hose I.D (mm)

6.4

Dash size

04

Hex A/F (E)

19

Cutoff - C

14

P01-0406

BSPP Female Thread (T)

1/4-19

Hose I.D inches

3/8

Hose I.D (mm)

9.5

Dash size

06

Hex A/F (E)

19

Cutoff - C

14

P01-0604

BSPP Female Thread (T)

3/8-19

Hose I.D inches

1/4

Hose I.D (mm)

6.4

Dash size

04

Hex A/F (E)

22

Cutoff - C

16

P01-0606

BSPP Female Thread (T)

3/8-19

Hose I.D inches

3/8

Hose I.D (mm)

9.5

Dash size

06

Hex A/F (E)

22

Cutoff - C

16

P01-0608

BSPP Female Thread (T)

3/8-19

Hose I.D inches

1/2

Hose I.D (mm)

12.7

Dash size

08

Hex A/F (E)

22

Cutoff - C

17

P01-0806

BSPP Female Thread (T)

1/2-14

Hose I.D inches

3/8

Hose I.D (mm)

9.5

Dash size

06

Hex A/F (E)

27

Cutoff - C

18

P01-0808

BSPP Female Thread (T)

1/2-14

Hose I.D inches

1/2

Hose I.D (mm)

12.7

Dash size

08

Hex A/F (E)

27

Cutoff - C

19

P01-0810

BSPP Female Thread (T)

1/2-14

Hose I.D inches

5/8

Hose I.D (mm)

15.9

Dash size

10

Hex A/F (E)

27

Cutoff - C

19

P01-0812

BSPP Female Thread (T)

1/2-14

Hose I.D inches

3/4

Hose I.D (mm)

19

Dash size

12

Hex A/F (E)

27

Cutoff - C

19

P01-1010

BSPP Female Thread (T)

5/8-14

Hose I.D inches

5/8

Hose I.D (mm)

15.9

Dash size

10

Hex A/F (E)

28

Cutoff - C

18

P01-1208

BSPP Female Thread (T)

3/4-14

Hose I.D inches

1/2

Hose I.D (mm)

12.7

Dash size

08

Hex A/F (E)

32

Cutoff - C

21

P01-1212

BSPP Female Thread (T)

3/4-14

Hose I.D inches

3/4

Hose I.D (mm)

19

Dash size

12

Hex A/F (E)

32

Cutoff - C

21

INTRODUCING NEW ENDURO SPIRAL HOSE

ENDURO spiral is an extremely flexible slim profile hose featuring our very high wear and abrasion resistant SuperTuff (ST) MSHA cover for increased protection against abrasion in severe operating environments.

VIEW ENDURO BROCHURE
