NUTS AND CUTTING RINGS

Product catalogue Adaptors NUTS AND CUTTING RINGS JIC TUBE NUT

JIC TUBE NUT

NUTS AND CUTTING RINGS

JIC TUBE NUT

TJNV

JIC TUBE NUT

JIC 37° FEMALE FLARELESS TUBE NUT

  • Tube nut for JIC 37° flareles steel tube connection.
  • Use with TJSV flareless tube sleeve.

JIC 37° FEMALE FLARELESS TUBE NUT

Download PDF
PartNumber
Tube OD
Tube Sleeve
T1 (UN)
H1
L1
TJNV-07
6.3 (1/4)
TJSV-04
7/16-20
14.3 (9/16)
21.0
TJNV-09
9.5 (3/8)
TJSV-06
9/16-18
17.5 (11/16)
21.8
TJNV-12
12.7 (1/2)
TJSV-08
3/4-16
22.2 (7/8)
27.4
TJNV-14
15.9 (5/8)
TJSV-10
7/8-14
25.4 (1)
28.4
TJNV-17
19.1 (3/4)
TJSV-12
1.1/16-12
31.8 (1.1/4)
34.5
TJNV-21
25.4 (1)
TJSV-16
1.5/16-12
38.1 (1.1/2)
35.6
TJNV-26
31.8 (1.1/4)
TJSV-20
1.5/8-12
50.8 (2)
45.7

Product Data

TJNV-07

Tube OD

6.3 (1/4)

Tube Sleeve

TJSV-04

T1 (UN)

7/16-20

H1

14.3 (9/16)

L1

21.0

TJNV-09

Tube OD

9.5 (3/8)

Tube Sleeve

TJSV-06

T1 (UN)

9/16-18

H1

17.5 (11/16)

L1

21.8

TJNV-12

Tube OD

12.7 (1/2)

Tube Sleeve

TJSV-08

T1 (UN)

3/4-16

H1

22.2 (7/8)

L1

27.4

TJNV-14

Tube OD

15.9 (5/8)

Tube Sleeve

TJSV-10

T1 (UN)

7/8-14

H1

25.4 (1)

L1

28.4

TJNV-17

Tube OD

19.1 (3/4)

Tube Sleeve

TJSV-12

T1 (UN)

1.1/16-12

H1

31.8 (1.1/4)

L1

34.5

TJNV-21

Tube OD

25.4 (1)

Tube Sleeve

TJSV-16

T1 (UN)

1.5/16-12

H1

38.1 (1.1/2)

L1

35.6

TJNV-26

Tube OD

31.8 (1.1/4)

Tube Sleeve

TJSV-20

T1 (UN)

1.5/8-12

H1

50.8 (2)

L1

45.7
